Analog-to-Digital Conversion
October 13th, 2011 |
Author:
The design of an analog-to-digital converter or digital-to-analog converter is one of the most fascinating tasks in micro-electronics. In a converter the analog world with all its intricacies meets the realm of the formal digital abstraction. Both disciplines must be understood for an optimum conversion solution. In a converter also system challenges meet technology opportunities. Modern systems rely on analog-to-digital converters as an essential part of the complex chain to access the physical world. And processors need the ultimate performance of digital-to-analog converters to present the results of their complex algorithms. The same progress in CMOS technology that enables these VLSI digital systems creates new challenges for analog-to-digital converters: lower signal swings, less power and variability issues. Last but not least, the analog-to-digital converter must follow the cost reduction trend. These changing boundary conditions require micro-electronics engineers to consider their design choices for every new design. Analog-to-Digital Conversion discusses the different analog-to-digital conversion principles: sampling, quantization, reference generation, nyquist architectures and sigma-delta modulation. It also presents an overview of the state-of-the-art in this field and focuses on issues of optimizing accuracy and speed while reducing the power level. A lot of background knowledge and practical tips complement the discussion of basic principles, which makes Analog-to-Digital Conversion also a reference for the experienced engineer.
Posted in
Analog-to-Digital Conversion
The design of an analog-to-digital converter or digital-to-analog converter is one of the most fascinating tasks in micro-electronics. In a converter the analog world with all its intricacies meets the realm of the formal digital abstraction. Both disciplines must be understood for an optimum conversion solution. In a converter also system challenges meet technology opportunities. Modern systems rely on analog-to-digital converters as an essential part of the complex chain to access the physical world. And processors need the ultimate performance of digital-to-analog converters to present the results of their complex algorithms. The same progress in CMOS technology that enables these VLSI digital systems creates new challenges for analog-to-digital converters: lower signal swings, less power and variability issues. Last but not least, the analog-to-digital converter must follow the cost reduction trend. These changing boundary conditions require micro-electronics engineers to consider their design choices for every new design.
Analog-to-Digital Conversion discusses the different analog-to-digital conversion principles: sampling, quantization, reference generation, nyquist architectures and sigma-delta modulation. It also presents an overview of the state-of-the-art in this field and focuses on issues of optimizing accuracy and speed while reducing the power level.
A lot of background knowledge and practical tips complement the discussion of basic principles, which makes Analog-to-Digital Conversion also a reference for the experienced engineer.
Digital Audio To Analog Audio Converter
Digital Audio To Analog Audio Converter
This handy Digital To Analog Audio converter box takes your coaxial/optical (S/PDIF or TOSLink) digital audio source and converts it to standard analog left/right audio, for connection to an external device such as an amplifier or recording deck via standard RCA-style jacks. Bridge your legacy sound system with digital sources such as DVD and CD players that don’t have RCA-style analog outputs.
Compact Profile
In a handsome white plastic chassis, this device is a small 1.65 x 0.87 x 1.59 inches in size, and weighs just 25g. It’s a breeze to set up and keep out of the way.
Handles Most Digital Signals
This box converts S/PDIF or TOSLink digital audio signals to analog L/R audio, accepting uncompressed digital audio at 32, 44.1, 48 and 96 KHz sample rates.
How it Works
Simply run a short extension cable from an available digital audio output jack on your digital source device to the same type of digital input on the Converter. Select which kind of digital signal (coaxial or optical) is being input with the selector switch on the converter, then hook up your analog RCA-style left and right cables to the Converter’s analog RCA jack outputs and power up all equipment.
**Please note that this product does not support encoded Dolby Digital audio. Verify you can turn off Dolby Digital in the source you will be connecting to this converter.
What’s in the Box
Gefen Digital Audio To Analog Audio Converter, Power Supply, User’s Manual
